Horizontal Bandsaw Pipe Bevelling Machine For Structural Steel Fabricators

Horizontal Bandsaw Pipe Bevelling Machine For Structural Steel Fabricators

1. Main features

● Double-column and double-cylinder structure greatly prolongs the service life of the machine, a unique feature exclusively owned by the company
● Hydraulic control of cutting speed, stepless speed regulation, angle cutting
● PLC controller, it could set program in advance for sawing process, feeding adopt grating ruler method, with functions of high speed and energy saving
● Including holding and clamping device

2. Main specifications

● Maximum sawing range: rectangular tube 800*800 mm, circular tube Φ800mm
● Maximum feeding length: 1500mm per time
● Cutting liner speed: 5 levels, 20/ 40/ 50/ 70/ 80 (belt, step speed changing)
● Cutting speed adjust method: 18-60m/min (hydraulic, stepless speed regulation)
● Saw blade size: 1.6*67*8420mm
● Saw blade tension method: manual lead screw tension
● Work feeding clamp method: double vise hydraulic clamp (hydraulic vise)
● Working table height: 615mm
● Control precision: ≤0.2/100mm
● Common sawing precision: ±0.20mm
● Main motor: 7.0Kw
● Hydraulic motor: 1.5Kw
● Saw blade cooling method: pump automatic recycle (cutting fluid)
● Saw blade cleaning: wire brush
● Machine dimension: 4300*2850*3200mm
● Gross weight: 3500Kg

cnc plasma cutter

pipe bevelling machine

Horizontal Bandsaw Pipe Bevelling Machine For Structural Steel Fabricators Images
